TOPIC: Transom mount bolts

Transom mount bolts 13 years 10 months ago #24161

Does anyone know where to purchase the aluminum bolts used to mount the transom brackets of early v4's? Would like to stay original if possible. Thanks

Please Log in or Create an account to join the conversation.

Re: Transom mount bolts 13 years 10 months ago #24165

The 1960 V4 parts diagram at Marineengine.com shows the transom bolts to be OMC #307221. A quick search on the same website shows the part number to have been replaced by #313327 and finally 336675 / 336676 (4 3/4" transom bolt). The last two appear to be interchangeable(?) and currently available from dealers.

Please Log in or Create an account to join the conversation.

Re: Transom mount bolts 13 years 10 months ago #24199

They quickly realized that aluminum was not the best material for the job.
They work well in the driveway but not in salt / brackish water.-The idea was short lived !
I believe I have some if I can find them, never to be installed ( by me )on a motor again.

Please Log in or Create an account to join the conversation.

Re:Transom mount bolts 13 years 10 months ago #24200

  • MarkS
  • MarkS's Avatar
  • Offline
  • Moderator
  • Moderator
  • Posts: 5348
  • Karma: 118
  • Thank you received: 5
Halcyondays, I've got a set (4) of four inch aluminum bolts (and nuts) you can have if you want them, just pay the shipping. (Not sure if they're long enough, if the parts list calls for 4 3/4") Email me your address if you do, I'll let you know what the $ is. I replaced mine recently with 4 1/2" Stainless Steel hardware when I installed the transom plates.
Attachments:

Please Log in or Create an account to join the conversation.

Mark
